Video Wall Controller
6.5M Pixels | 10 Gigabit Ports | Ultra-Wide Screens
TN25-6P
TN25-6P is an all-in-one video wall controller integrating video processing and control into a single unit for LED video wall applications. Engineered for medium and high-end rental, stage control systems, and fine-pitch LED screens, it features 10 Gigabit Ethernet ports driving up to 6.5 million pixels with maximum output dimensions of 10,240 pixels wide and 8192 pixels high—ideal for ultra-wide and ultra-high LED screen configurations. Supporting diverse input sources including HDMI 1.4, 3G-SDI, DVI, and self-adaptive optical fiber (OPT 1), the controller processes high-resolution images with stepless output scaling, pixel-level brightness and chroma calibration, and low latency performance.
Three working modes (Video Controller, Fiber Converter, Bypass) enable flexible deployment while redundant hot backup architecture ensures continuous operation. With GUI-based management supporting multi-window layouts (2×2, 3×3, custom), independent layer resizing, positioning, and audio input/output capabilities, TN25-6P delivers professional-grade control for TraffiVue LED video walls across highway command centers, smart city control rooms, and mission-critical traffic management installations.
Product Highlights
6.5M Pixel Capacity
Drives up to 6.5 million pixels per unit with maximum output dimensions of 10,240 pixels width and 8192 pixels height. Ideal for ultra-wide LED screens across expansive command center installations without requiring multiple controller units.
Gigabit Ethernet Outputs
Ten Gigabit Ethernet ports provide comprehensive LED screen connectivity with flexible output distribution. Ports 1 and 2 support audio output enabling synchronized audio-visual content delivery through multifunction cards.
Self-Adaptive OPT 1 Port
Optical fiber port OPT 1 automatically adapts as either video input or sending card output depending on connected device. Supports up to 4K×1K@60Hz or 2×2K×1K@60Hz video inputs enabling flexible fiber-based connectivity.
Low Latency & Hot Backup
Reduce delay to 20 lines when low latency and Bypass mode enabled ensuring real-time video display. Multiple hot backup options including device-level redundancy maintain continuous operation during component failures.
Input Connectors
| Connector | Specification |
|---|---|
| HDMI 1.4 × 2 (with loop) | Max: 3840×1080 @ 60Hz or 3840×2160 @ 30Hz; HDCP 1.4; Custom resolutions up to 4092×1136 @ 60Hz (width) or 1060×3981 @ 60Hz (height) |
| DVI × 1 (with loop) | Max: 3840×1080 @ 60Hz or 3840×2160 @ 30Hz; HDCP 1.4; Custom resolutions supported |
| 3G-SDI × 1 (with loop) | Max: 1920×1080 @ 60Hz; ST-424 (3G), ST-292 (HD), ST-259 (SD) standards; Deinterlacing supported |
| OPT 1 × 1 | Self-adaptive: Input or output mode; Supports 1× 4K×1K @ 60Hz or 2× 2K×1K @ 60Hz video inputs |
Output Connectors
| Connector | Specification |
|---|---|
| Gigabit Ethernet × 10 | Up to 6.5M pixels total; Max width: 10,240 pixels; Max height: 8192 pixels; Ports 1 & 2 support audio output |
| OPT 2 × 1 | Output only; Copies or backs up output on Ethernet ports |
| HDMI 1.3 × 1 | Monitor and video output modes; Adjustable resolution |
Key Specifications
| Parameter | Specification |
|---|---|
| Max Loading Capacity | 6.5 million pixels |
| Max Output Width | 10,240 pixels |
| Max Output Height | 8192 pixels |
| Multi-Window Layouts | 2×2, 3×3, custom configurations |
| Layer Control | 3 × layers with adjustable size, position, priority |
| Video Processing | Stepless output scaling, pixel-level calibration |
| Audio | Input via HDMI source; Output via multifunction card (Ethernet 1 or 2) |
| Working Modes | Video Controller, Fiber Converter, Bypass |
| Latency | 20 lines (low latency + Bypass mode enabled) |
| Power Supply | 100-240V~, 1.5A, 50/60Hz |
| Power Consumption | 35W rated |
Operating & Physical Specifications
| Parameter | Specification |
|---|---|
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 20-90% RH, non-condensing |
| Storage Temperature | -20°C to +70°C |
| Storage Humidity | 10-95% RH, non-condensing |
| Dimensions (W×D×H) | 483.6 × 351.2 × 50.1 mm |
| Net Weight | 4 kg |
| Noise Level | 45 dB(A) @ 25°C |
Compatible Video Wall Displays
Applications and Deployment
Professional LED video wall control for traffic management and command center installations.
Highway Traffic Management Centers
Controls TraffiVue LED video walls displaying real-time expressway CCTV feeds with pixel-level calibration ensuring color consistency across expansive displays. Low latency performance maintains real-time visualization supporting rapid incident response and traffic flow coordination.
Smart City Command & Control Rooms
Manages multi-source content across large LED video walls with independent layer control enabling priority content highlighting. Three working modes support diverse deployment scenarios from fiber-based connectivity to direct Ethernet configurations.
Stage & Event Control Systems
Drives ultra-wide LED screens for conferences, presentations, and control room briefings with stepless output scaling. Preset saving and loading capabilities enable rapid configuration switching adapting to varying content requirements.
Why Choose TN25-6P?
All-in-one LED video wall processing backed by professional-grade features and reliability.
Ultra-Wide Screen Support
6.5 million pixel capacity with 10,240 pixels maximum width supports expansive LED video wall configurations across control rooms. Single-unit design eliminates need for multiple controllers reducing system complexity and potential failure points.
Flexible Fiber Connectivity
Self-adaptive OPT 1 port automatically switches between input and output modes depending on connected device. Supports up to 4K×1K@60Hz video inputs enabling long-distance fiber-based connections between source devices and display.
Professional Image Quality
Pixel-level brightness and chroma calibration removes color discrepancies across LED panels improving display uniformity. All-round color adjustment including brightness, contrast, saturation, hue, and Gamma ensures accurate visualization.
Multiple Hot Backup
Device-level backup architecture with OPT 2 output redundancy ensures continuous operation during component failures. Critical for 24×7 traffic management environments requiring uninterrupted video wall visualization.
Three Working Modes
Video Controller mode for direct LED screen control, Fiber Converter mode for signal transmission, and Bypass mode for low latency applications. Flexible mode switching adapts to diverse installation requirements without hardware changes.
GUI Management Simplicity
Intuitive graphical interface eliminates command-line complexity enabling rapid window configuration and layout adjustments. Up to 10 user-defined presets support quick switching between common display configurations.
Drive Your LED Video Wall with Professional Control
All-in-one controller supporting 6.5M pixels and ultra-wide screens up to 10,240 pixels for TraffiVue LED video walls.
