TraffiVue TN SMD
TraffiVue TN SMD is a standard-pitch LED video wall series engineered for control rooms, command centers, and conference facilities requiring versatile display solutions. Available in five pixel pitch variants from 1.25mm to 2.5mm (TN 1.2, TN 1.5, TN 1.8, TN 1.9, TN 2.5), it delivers flexible configurations balancing resolution, viewing distance, and cost optimization for highway traffic management centers and smart city command facilities. The modular 640×480mm die-cast aluminum cabinets feature 16:9 aspect ratio with front or rear serviceability supporting seamless splicing across installations from compact monitoring walls to expansive control room displays.
With ≥600 nits brightness, 5000:1 contrast ratio, and ≥3840Hz refresh rate, the TN series ensures clear visualization of real-time CCTV feeds, traffic dashboards, and ITS data across 24×7 operations. The constant current drive with 16-bit color depth delivers accurate color reproduction while ≥160° viewing angles maintain image quality for operators across control room positions maintaining reliability in -10°C to +45°C environments.
Product Highlights
Five Pixel Pitch Options
Choose from 1.25mm, 1.53mm, 1.86mm, 1.99mm, or 2.5mm pitch variants optimizing resolution versus viewing distance for specific applications. Pixel density ranges from 160,000 to 640,000 pixels/m² enabling tailored configurations matching control room layout and operator positioning requirements.
640×480mm Modular Cabinets
Standardized 0.3072m² die-cast aluminum cabinets with 2×3 module configuration enable flexible wall sizing and replacement. Lightweight ≤7kg cabinet weight simplifies installation and serviceability while maintaining structural integrity across expansive video wall deployments.
≥ 3840Hz Refresh
Ultra-high ≥3840Hz refresh rate eliminates flicker ensuring operator eye comfort during extended control room shifts. 16-bit color depth with adjustable 5000-10000K color temperature delivers accurate visualization of traffic CCTV feeds and analytics dashboards.
Front/Rear Serviceability
Dual servicing options (front or rear access) support diverse installation environments from free-standing walls to recessed mounting configurations. Modular design enables rapid module replacement minimizing downtime during maintenance operations.
Available Configurations
| Model | Pixel Pitch | LED Type | Module Resolution | Pixels/m² | Cabinet Resolution |
|---|---|---|---|---|---|
| TN 1.2 | 1.25 mm | TOP 1010 | 256×128 | 6,40,000 | 512×384 |
| TN 1.5 | 1.53 mm | TOP 1212 | 208×104 | 4,22,500 | 416×312 |
| TN 1.8 | 1.86 mm | TOP 1515 | 172×86 | 2,88,906 | 344×258 |
| TN 1.9 | 1.99 mm | TOP 1817 | 160×80 | 2,50,000 | 320×240 |
| TN 2.5 | 2.5 mm | TOP 2121 | 128×64 | 1,60,000 | 256×192 |
Key Specifications
| Parameter | Specification |
|---|---|
| Cabinet Size (W×H×D) | 640×480×49 mm |
| Cabinet Area | 0.3072 m² |
| Cabinet Material | Die-cast aluminum |
| Module Size | 320×160 mm |
| Modules Per Cabinet | 2×3 (6 modules) |
| Servicing | Front / Rear |
| Brightness | ≥600 nits |
| Contrast Ratio | 5000:1 (max) |
| Viewing Angle (H/V) | ≥160° / ≥160° |
| Color Temperature | 5000K - 10000K (adjustable) |
| Refresh Rateh | ≥ 3840 Hz |
| Frame Rate | 30-120 Hz |
| Color Depth | 16 bit |
| Drive Mode | Constant current drive |
| Cabinet Weight | ≤7 kg |
Power & Environment
| Parameter | Specification |
|---|---|
| Input Voltage | AC 220V ±15% |
| Max Power Consumption | ≤550 W/m² |
| Average Power Consumption | ≤250 W/m² |
| Operating Temperature | -10°C to +45°C |
| Storage Temperature | -20°C to +60°C |
| Operating Humidity | 10-90% RH |
| Storage Humidity | 10-70% RH |
| IP Rating | IP3X (IP5X with QCOB) |
| Lifespan | 100,000 hours |
Recommended Viewing Distances
| Pixel Pitch | Optimal Viewing Distance - Application |
|---|---|
| TN 1.2 (1.25mm) | 1.5-3 meters - Close monitoring stations |
| TN 1.5 (1.53mm) | 2-4 meters - Front-row operator positions |
| TN 1.8 (1.86mm) | 2.5-5 meters - Mid-distance control rooms |
| TN 1.9 (1.99mm) | 3-6 meters - Standard control room walls |
| TN 2.5 (2.5mm) | 4-8 meters - Large-scale monitoring walls |
Applications and Deployment
Scalable LED video walls for traffic management, smart city, and control room applications.
Highway Traffic Management Centers
Displays real-time expressway CCTV feeds with pixel pitch selection matching viewing distances from close operator positions to wall-mounted displays. Modular 640×480mm cabinets enable flexible configurations adapting to existing control room layouts without extensive infrastructure modifications.
Smart City Command & Control Rooms
Monitors urban traffic intersections, ANPR feeds, and analytics dashboards across scalable video walls from compact 2×2 arrays to expansive installations. ≥3840Hz refresh rate ensures smooth video playback while 16-bit color depth maintains visualization accuracy for evidence-based decision-making.
Conference & Presentation Facilities
Provides high-resolution visualization for presentations, video conferencing, and collaborative sessions requiring flexible content display. Front-serviceable design enables maintenance without disrupting adjacent spaces while die-cast aluminum construction ensures structural reliability.
Why Choose TraffiVue TN SMD?
Unparalleled cost-performance backed by revolutionary energy efficiency and operator wellness innovation.
Five Pitch Options
Choose optimal pixel pitch balancing resolution, viewing distance, and budget requirements for specific control room layouts. TN 1.2 (1.25mm) for close viewing applications down to TN 2.5 (2.5mm) for economical large-scale installations.
Standardized Cabinet Design
640×480mm modular cabinets with 16:9 aspect ratio simplify wall design and enable seamless expansion as monitoring requirements grow. Lightweight ≤7kg construction facilitates installation while maintaining structural integrity across multi-year deployments.
High Refresh Anti-Flicker
≥3840Hz refresh rate eliminates flicker ensuring operator eye comfort during extended 24×7 control room shifts. Smooth video playback of real-time CCTV feeds prevents motion blur supporting accurate incident assessment and response coordination.
Dual Servicing Options
Front or rear serviceability supports diverse installation environments from free-standing walls to recessed mounting configurations. Modular module design enables rapid component replacement minimizing downtime during maintenance operations without wall dismounting.
Proven Control Room Reliability
100,000-hour lifespan with constant current drive ensures consistent brightness and color accuracy across multi-year operations. -10°C to +45°C operating range supports deployment in climatically diverse Indian highway control centers.
Cost-Effective Scalability
Standard pitch technology delivers optimal price-performance ratio compared to ultra-fine pitch alternatives for medium-viewing-distance applications. Modular architecture enables phased deployment matching budget availability while maintaining visual continuity.
Build Your Control Room Video Wall
Choose from five pixel pitch options (1.25-2.5mm) with modular die-cast aluminum cabinets for scalable LED video wall solutions.
